Product Details:
|
| Material: | Adheisve Granules And PE | Color: | Transparent |
|---|---|---|---|
| Usage: | Plywood | Future: | Excellent Peel Strength And Low Costs |
| Manufacturing Method: | Blow Film | Structure: | Three Layers With Double Side Adhesive Resins |
| Highlight: | 60 Microns Double Sided Adhesive Film,Double Sided Adhesive Film Transparent,plywood double sided sticky film |
||
Grade:AF8160
Product:60 Microns Excellent Peel Strength Adhesive Film for plywood lamination
Decriptions
The polymer adhesive is a maleic anhydrie functionalized vinyl hot melt adhesive film,developed from years of theoretical and application experience in the field of hot melt adhesive film. The compounding temperature of the product is low, and the compounding process will not cause deformation or damage to the wood-based material. The material can form a good bonding effect.
AF8160 is a polymer adhesive film product for plywood lamination. Plywood is one of the three wood-based panels commonly used in furniture. The veneer is made of slabs that are crisscrossed in the direction of the wood grain, and pressed under heating conditions. The polymer adhesive film is paved between the veneers. Pressurized and high temperature compounding has high bonding strength, low cost, environmental protection and no formaldehyde. It is an efficient and environmentally friendly product to replace tri-aldehyde glue and soybean glue.
Application
AF8160 polymer adhesive film is used for plywood lamination,which is used for decoration panel,furniture,wood door and floor etc.
Advantages
Excellent bonding strength
Processing temperature is low and keep the wood performance well without damage or deformation
Low costs and environmental protection and no formaldehyde
Physical Properties
| Item | Unit | Testing Standard | 60 microns thickness | Remark |
| Density | g/cm3 | ASTM D1505 | 0.968 | |
| Elongation at Break | % | ASTM D638 | >400 | |
| Peel Strength | N/mm | GB/T 2790-1995 | >12 | |
| Melt Point | ℃ | DSC | 125 | |
| Width | Mm | GB/T 6673-1986 | ±5 | |
| Thickness | Mm | GB/T 6672-1986 | ±0.002 |
♦These are typical properties and not intended as specification
Specifications:
Width: 50mm-1600mm (Customization available)
Length: 1500m/ roll or customization
Processing Suggestions :
Adhesive Layer Structure: Wood+AF8160+Wood and so on
Bonding Temperature: 165℃-195℃
Bonding Press Force: > 12 kg/cm2
QC Standard: IS09001:2015
Packing and Storage:
12 Rolls/Pallet,60- 80 KG/Roll (Customization available)；
Keep in a dry cool place. Avoid direct sunlight, ventilation, and moisture. The storage period at room temperature is 12 months. If the film color changes and elongation is found to decrease by 50%, do not use it.
