Product Details:
|
| Material: | Maleic Anhydride Functionalized Vinyl Hot Melt Granule | Color: | Clear |
|---|---|---|---|
| Usage: | Bi-metal Heat-insulating Panel,Steel-Aluminium Composite Panel | Future: | Excellent Bonding Strength With High Content Adhesive Granule |
| Manufacturing Method: | Blow Film | Structure: | Three Layers With Double Side Adhesive Granules |
| Highlight: | 35 Microns Double Sided Adhesive Film,Double Sided Adhesive Film Clear,Clear double sided sticky film |
||
Grade:AF8035
Product:35 Microns Excellent Bonding Strength Polymer Adhesive Film For Bi-Metal Heat-Insulating Panel
Decriptions
The polymer adhesive film for Bi-metal Heat-insulating panel is based on the comprehensive research of domestic and overseas Bi-metal bonding, combined with the independent intellectual property rights. This adhesive film has been successfully developed with many years of R&D and application experience.It greatly promotes the innovation of heat-insulating panel and rapid development of the industry.
AF8035 Polymer adhesive film is for Bi-metal heat-insulation panel, it uses color steel plate or galvanized plate as the base plate, and the surface of the base plate is covered with aluminum foil, and the anti-aging polymer adhesive film is used to laminate the aluminium foil with the color steel plate at suitable temperature, It is an environment friendly and safe product with good processing performance, and suitable for continuous and automatic processing.
Application
AF8035 polymer adhesive film is used for Bi-metal heat-insulation panel ,Thermal insulation color steel plate (color aluminum plate), Building thermal insulation tile,or other products made of steel and aluminum composite.
Advantages
Excellent bonding strength with galvanized steel or color steel plate with aluminum foil
Excellent resistance to Acid and Alkali and high UV resistance
Good anti-aging and long-lasting bonding performances
good durability of bonding, good processing performance, good weather resistance, applicable for different climate and temperature.
Physical Properties
| Item | Unit | Testing Standard | 35 microns thickness | Remark |
| Density | g/cm3 | ASTM D1505 | 0.931 | |
| Melting Point | ℃ | DSC | 108 | |
| Peel Strength | N/mm | ＞11 | ||
| Width | Mm | GB/T 6673-1986 | ±5 | |
| Thickness | Mm | GB/T 6672-1986 | ±0.002 |
♦These are typical properties and not intended as specification
Specifications:
Width: 50mm-1600mm (Customization available)
Length: 1500m/ roll or customization
Processing Suggestions :
Adhesive Layer Structure: Color Steel Sheet or galvanized plate +AF8035+ Aluminium Foil
Bonding Temperature: 155℃-170℃
QC Standard: IS09001:2015
Packing and Storage:
12 Rolls/Pallet,60- 80 KG/Roll (Customization available)；
Keep in a dry cool place. Avoid direct sunlight, ventilation, and moisture. The storage period at room temperature is 12 months. If the film color changes and elongation is found to decrease by 50%, do not use it.
Remarks: The above information and technical data are based on our existing product knowledge and experience. We do not guarantee the above content and do not assume legal responsibility. Customers must do a sample test before using our products to ensure the best processing conditions.
