Product Details:
|
| Film Thickness: | 20 Microns | Material: | Adhesive Resins And PE |
|---|---|---|---|
| Color: | Transparent | Usage: | Bonding PE Core Material With Aluminium Coil |
| Future: | Good Pulverization Effect And High Adhesion | Shape: | Films |
| Packing: | 60-80 Kgs/Roll | Structure: | Three Layers |
| Highlight: | Excellent Pulverization Effect polymer thin film,polymer thin film 20 Microns,Transparent hot melt adhesive web |
||
Grade:AF1020
Product:Excellent Pulverization Effect Adhesive Films For Alumunium Composite Panel Films
Specifications:
Width: 50mm-1600mm (Customization available)
Length: 3000m/roll or customization
Processing Suggestions :
Adhesive Layer Structure: AL+AF1020+PE+AF1020+AL
Bonding Temperature: 145°C-170°C (Actual Temperature of the
Equipment)
Metal Surface: Phosphating or chromizing treatment and pre-degreasing treatment can avoid dust pollutants.
Decriptions
The polymer adhesive film for aluminum composite panels (ACP) and other metal aluminum bonding polyethylene composite products. ACP is made up of multi-layer materials. Both the upper and lower layers are high-purity aluminum alloy sheets, the middle layer is non-toxic low- density polyethylene (PE) core sheet.
AF1020 adhesive film is three layers film with 30% adhesive resins,it has excellent pulverization effect with good bonding strength. And all the raw materials are virgin,for which ensure the products quality stable.
Application
AF1020 adhesive film is widely for thin aluminium composite panel and partial panels, it’s better to used for the aluminium coil thickness 0.08mm of the ACP.
Advantages
a. Excellent bonding strength
b. Excellent resistance to Acid and Alkali and high UV resistance
Good anti-aging and long-lasting bonding performances
c. Suitable for normal aluminum composite panels
Physical Properties:
| Item | Unit | Testing Standard |
Thickness 20 microns |
Remark |
| Density | g/cm3 | ASTM D1505 | 0.93 | |
| Tensile Strength | MPa | ASTM D638 | 27 | |
| Elongation at Break | % | ASTM D638 | >400 | |
| Peel Strength | N/mm | GB/T 2790-1995 | >4 | |
| Width | Mm | GB/T 6673-1986 | ±5 | |
| Thickness | Mm | GB/T 6672-1986 | ±0.002 |
Remark: These are typical properties only and are not to be regarded as sales specifications
Packages and Storage
1.12 Rolls/Pallet, 60-80 KG/Roll (Customization available)；
2.Keep in a dry cool place. Avoid direct sunlight, ventilation, and moisture. The storage period at room temperature is 12 months. If the film color changes and elongation is found to decrease by 50%, do not use it.
