Product Details:
|
| Film Thickness: | 30 Microns | Material: | Virgin Adhesive Resins And PE |
|---|---|---|---|
| Color: | Transparent | Usage: | Films For Aluminium Composite Panel Or Other Matal |
| Future: | Good Bonding Performance | Structure: | Three Layers |
| Highlight: | 30 Microns Polymer Thin Films,Polymer Thin Films Excellent Bonding Strength,Three Layers hot melt glue film |
||
Grade:AF1030
Product name:Excellent Bonding Strength Adhesive Films For Alumunium Composite Panel Films
Physical Properties:
| Item | Unit | Testing Standard |
Thickness 30 microns |
Remark |
| Density | g/cm3 | ASTM D1505 | 0.93 | |
| Tensile Strength | MPa | ASTM D638 | 27 | |
| Elongation at Break | % | ASTM D638 | >400 | |
| Peel Strength | N/mm | GB/T 2790-1995 | >5 | |
| Width | Mm | GB/T 6673-1986 | ±5 | |
| Thickness | Mm | GB/T 6672-1986 | ±0.002 |
Decriptions
The adhesive film for aluminum composite panels (ACP) and other metal plastic composite products. It is based on the comprehensive research of domestic and overseas aluminum adhesive, combined with the independent intellectual property rights. The polymer film is a high-performance film made of scientific formula design and precise process control.
AF1030 adhesive film is three layers film with 35% adhesive resins,it has excellent pulverization effect with good peel strength. And all the raw materials are virgin,for which ensure the products quality stable.
Application
AF1030 adhesive film is widely for thin aluminium composite panel and partial panels and decoration panels, it’s better to used for the aluminium coil thickness 0.12-0.2 mm of the ACP.
Advantages
a. Excellent bonding strength
b. Excellent resistance to Acid and Alkali and high UV resistance
c. Good anti-aging and long-lasting bonding performances
d. Suitable for normal aluminum composite panels
Specifications:
Width: 50mm-1600mm (Customization available)
Length: 2500m/roll or customization
Processing Suggestions :
Adhesive Layer Structure: AL+AF1030+PE+AF1030+AL
Bonding Temperature: 145°C-170°C (Actual Temperature of the
Equipment)
Packages and Storage
1.12 Rolls/Pallet, 60-80 KG/Roll (Customization available)；
2.Keep in a dry cool place. Avoid direct sunlight, ventilation, and moisture. The storage period at room temperature is 12 months. If the film color changes and elongation is found to decrease by 50%, do not use it.
